Ingersoll Rand

216B 3/8″ Straight Air Impact Wrench

With its compact and accessible design, the 216B Impact Wrench is a standout for ensuring excellence in every job. Its aluminum hammer case and robust metal housing, offers a lightweight yet sturdy solution for your needs. Its advanced ball and cam mechanism provides potent, consistent power to make quick work of even the most demanding tasks without the risk of stalling. Ideal for vehicle repair, the straight grip and slim profile of the 216B make it the perfect companion for working within tight spaces.

Item No :
216B 3/8″ Straight Air Impact Wrench
Order(MOQ) :
1PC
Payment :
T/T
Product Origin :
China
Color :
Black
Shipping Port :
Xiamen
Lead Time :
15days

Inquiry now

Product Details
Model Specifications

Features

Robust Durability:

Crafted with an aluminum hammer case and metal housing, the 216B Impact Wrench is engineered to withstand rigorous use while remaining lightweight and easy to control.

Powerful Performance:

The innovative ball and cam mechanism ensures a high power output, allowing you to work efficiently without the worry of tool stalling.

Easy Access Design:

With its straight grip and streamlined build, the 216B is specially designed to navigate and perform in hard-to-reach areas.

Vehicle Repair:

This air impact wrench is an indispensable tool for vehicle maintenance, providing the power and access needed to make repairs with confidence and ease.

Model	Configuration	Actuation	Drive Size	Drive Type	Forward Torque (ft-lbs)	Forward Torque (Nm)	Max Reverse Torque (ft-lbs)	Max Reverse Torque (Nm)	Blows per minute	Free Speed (RPM)	Impacting Sound Level dB(A) -- ISO15744 (pressure/power)	Free Speed Sound Level dB(A) -- CAGI/ANSI S12.41 (pressure/power)	Vibration Level m/s2 (K)	Weight (lbs)	Weight (kg)	Length (in)	Length (mm)	Air Inlet	Min Hose Size (in)	Min Hose Size (mm)	Air Consumption @ Load (cfm)	Air Consumption @ Load (L/min)	Average Air Consumption (cfm)	Average Air Consumption (L/min)	PSI	Bar
216B	Straight	Butterfly	3/8 in.	Square, Hog-Ring	200	271	200	271	1600	8500	90.0 / 101.0	94.8 / 105.8	5.2 (1)	2.8	1.27	7.7	196	1/4 in.	3/8	10	19	538	3	85	90	6.2
