Model | Actuation | Max. Working Torque (Nm) | Max. Working Torque (in-lb) | Free Speed (rpm) | Weight with Chuck (kg) | Weight with Chuck (lb) | Length with Chuck (mm) | Length with Chuck (in) | Bit Holder Capacity (in) | Bit Holder Capacity (mm) | Side to Center (mm) | Side to Center (in) | Sound Level dB(A) | Rated Power (hp) | Air Inlet | cfm |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
5LK1 | Lever | 3.4 | 30.1 | 3.1 | 0.91 | 2 | 206 | 8.1 | 1/4 | 6.35 | 20.32 | 0.8 | 74.6 | 0.4 | 1/4" NPT | 16 |
5LL1 | Lever | 4.5 | 39.8 | 2300 | 0.91 | 2 | 206 | 8.1 | 1/4 | 6.36 | 20.32 | 0.9 | 72.3 | 0.4 | 1/4" NPT | 15 |
5LN3 | Lever | 9.01 | 79.7 | 1000 | 1.5 | 3.3 | 239 | 9.4 | 3/8 | 9.53 | 20.32 | 0.8 | 75.6 | 0.4 | 1/4" NPT | 15 |
