Model |
Actuation |
Voltage |
Torque Range (Nm) |
Torque Range (in-lbs) |
Free Speed (rpm) |
Weight (kg) |
Weight (lb.) |
Length (mm) |
Length (in) |
Spindle Type |
Controller Required |
Controller Input Voltage |
Controller Output Voltage |
Controller Weight (kg) |
Controller Weight (lbs) |
Controller Dimensions L x W x H (mm) |
Controller Dimensions L x W x H (in) |
Controller Soft Start |
Controller Speed Adjustment |
ESD Control |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EL0410BC-SS-ESD |
Inline - Lever With Soft Stop |
24 V DC (EC24N-ESD) |
0.19 - 0.40 |
1.7 - 3.5 |
700 - 1,000 |
0.4 |
0.9 |
267 |
10.5 |
4 mm Quick Change |
EC24N-ESD |
115 V AC |
24 V DC |
2.3 |
5.1 |
267 x 83 x 104 |
10.5 x 3.3 x 4.1 |
Yes |
Yes |
Yes |
|
EL0510BC-SS-ESD |
Inline - Lever With Soft Stop |
24 V DC (EC24N-ESD) |
0.25 - 0.55 |
2.2 - 4.9 |
700 - 1,000 |
0.4 |
0.9 |
267 |
10.5 |
4 mm Quick Change |
EC24N-ESD |
115 V AC |
24 V DC |
2.3 |
5.1 |
267 x 83 x 104 |
10.5 x 3.3 x 4.1 |
Yes |
Yes |
Yes |
|
EL0807BC-SS-ESD |
Inline - Lever With Soft Stop |
24 V DC (EC24N-ESD) |
0.45 - 0.95 |
3.9 - 8.2 |
500 - 700 |
0.4 |
0.9 |
267 |
10.5 |
4 mm Quick Change |
EC24N-ESD |
115 V AC |
24 V DC |
2.3 |
5.1 |
267 x 83 x 104 |
10.5 x 3.3 x 4.1 |
Yes |
Yes |
Yes |
|
EL1007BC-ESD |
Lever Start |
24 V DC (EC24N-ESD) |
0.19 - 1.2 |
1.7 - 10.4 |
500 - 700 |
0.4 |
0.9 |
267 |
10.5 |
1/4 in. Hex Quick Change |
EC24N-ESD |
115 V AC |
24 V DC |
2.3 |
5.1 |
267 x 83 x 104 |
10.5 x 3.3 x 4.1 |
Yes |
Yes |
Yes |
|
EL1007BC-SS-ESD |
Inline - Lever With Soft Stop |
24 V DC (EC24N-ESD) |
0.55 - 1.2 |
4.8 - 10.4 |
500 - 700 |
0.4 |
0.9 |
267 |
10.5 |
4 mm Quick Change |
EC24N-ESD |
115 V AC |
24 V DC |
2.3 |
5.1 |
267 x 83 x 104 |
10.5 x 3.3 x 4.1 |
Yes |
Yes |
Yes |
|
EL0109E |
Inline - Lever Start |
24 V DC (EC24E) |
0.03 - 0.15 |
0.26 - 1.32 |
650 - 950 |
0.32 |
0.7 |
235 |
9.3 |
4 mm Quick Change |
EC24E |
230 V AC |
24 V DC |
2.3 |
5.1 |
267 x 83 x 104 |
10.5 x 3.3 x 4.1 |
Yes |
Yes |
No |
|
EL0410E |
Inline - Lever Start |
24 V DC (EC24E) |
0.06 - 0.5 |
0.53 - 4.43 |
750 - 1,000 |
0.36 |
0.8 |
235 |
9.3 |
1/4 in. Hex Quick Change |
EC24E |
230 V AC |
24 V DC |
2.3 |
5.1 |
267 x 83 x 104 |
10.5 x 3.3 x 4.1 |
Yes |
Yes |
No |
|
EL1007E |
Inline - Lever Start |
24 V DC (EC24E) |
.55 - 1.2 |
4.9 - 11 |
500 - 700 |
0.36 |
0.8 |
235 |
9.3 |
1/4 in. Hex Quick Change |
EC24E |
230 V AC |
24 V DC |
2.3 |
5.1 |
267 x 83 x 104 |
10.5 x 3.3 x 4.1 |
Yes |
Yes |
No |
