Model | Configuration | Actuation | Drive Size | Drive Type | Forward Torque ft-lbs (Nm) | Max Reverse Torque ft-lbs (Nm) | Blows Per Minute | Free Speed (RPM) | Impacting Sound Level dB(A) -- ISO15744 (pressure/power) | Free Speed Sound Level dB(A) -- CAGI/ANSI S12.41 (pressure/power) | Vibration Level m/s2 (K) | Weight lbs (kg) | Length in (mm) | Air Inlet Size | Min Hose Size (in) | Air Consumption @ Load cfm (L/min) | PSI | Bar |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1712B2 | D-Handle | Inside Trigger | 1 in. | Square, Thru-Hole | 1400 (1898) | 1400 (1898) | 800 | 6000 | 103.0 / 114.0 | 107.7 / 118.7 | 19.7 (3.6) | 18.25 (8.28) | 11.25 (286) | 1/2" NPT | 3/4 | 47 (1331) | 90 | 6.2 |
