QA6 Series Handheld Angle Adjustable Shut-Off Air Nutrunner

QA6 Series Handheld Angle Adjustable Shut-Off Air Nutrunner

This nutrunner is made for maximum flexibility. With a conveniently placed reverse ring and 360-degree indexed angle head you can get any job done, no matter how hard to reach. The adjustable shut-off clutch is built for fastening and limits torque reaction.

  • Item No :

    QA6 Series Handheld Angle Adjustable Shut-Off Air Nutrunner
  • Order(MOQ) :

    1PC
  • Payment :

    T/T
  • Product Origin :

    China
  • Color :

    Black
  • Shipping Port :

    Xiamen
  • Lead Time :

    15days
  • Weight :

    2.3kg

This nutrunner is made for maximum flexibility. With a conveniently placed reverse ring and 360-degree indexed angle head you can get any job done, no matter how hard to reach. The adjustable shut-off clutch is built for fastening and limits torque reaction.

Features

Accurate:



Adjustable External clutch for Delivering Consistent Torque Results

Durability:



Spend your time working, not waiting for repair. QA series has been tested for 1 Million cycles without failure

Easy to Use:



The 360-degree indexing of angle head allows you to position the tool the way you want, while the position of the reverse ring is optimized for user comfort.



Model

Actuation

Torque Range (Nm)

Torque Range (ft-lb)

Free Speed (rpm)

Weight (kg)

Weight (lb)

Length (mm)

Length (in)

Angle Head Side to Center (mm)

Angle Head Side to Center (in)

Angle Head Height (mm)

Angle Head Height (in)

Air Inlet

cfm

Spindle Type

Common Fastener Size

Sound (dBA)

QA6AALS030NP35S06

Lever Start

15 - 30

11.1 - 22.1

580

2.29

5.05

429

16.9

18

0.69

44

1.71

3/8 in. NPT

36

3/8 in. Square

M8

82.5

QA6AALS040NP35S06

Lever Start

20 - 40

14.8 - 29.5

430

2.29

5.05

429

16.9

18

0.69

44

1.71

3/8 in. NPT

36

3/8 in. Square

M8

82.5

QA6AALS040NP35S08

Lever Start

20 - 40

14.8 - 29.5

430

2.3

5.07

429

16.9

18

0.69

44

1.71

3/8 in. NPT

36

1/2 in. Square

M8

82.5

QA6AALS055NP35S08

Lever Start

25 - 55

18.4 - 40.6

320

2.3

5.07

429

16.9

18

0.69

44

1.71

3/8 in. NPT

36

1/2 in. Square

M10

82.5

QA6AALS070NP43S08

Lever Start

35 - 70

25.8 - 51.6

225

2.3

5.07

422

16.6

22

0.85

45

1.76

3/8 in. NPT

36

1/2 in. Square

M10

82.5

QA6AALS090NP43S08

Lever Start

45 - 90

33.2 - 66.4

185

2.3

5.07

422

16.6

22

0.85

45

1.76

3/8 in. NPT

36

1/2 in. Square

M10 - M12

82.5
