Technical Specifications | |
Imperial Metric | Dimension & weight |
Dimension & weight | |
Height | 88.6 mm |
Length | 254 mm |
width | 74.6 mm |
Output size | IQ-13 |
Weight | 2.25 lb |
Certifications, standards & directives | |
CCC certified | No |
CMIIT ID | 2020AJ14906 |
EAC certified | Yes |
EU Standard | EN 300 328 V2.2.2||EN 300 440 V2.1.1||EN 301 489-1 |
V2.1.1||EN 301 489-17 V3.2.4||EN 301 893 V2.1.1||EN | |
50566:2017||EN 55014-1:2017||EN 55014-2:2015||EN | |
61000-6-2:2005||EN 61000-6-3:2007+A1||EN 61000-6- | |
4:2007+A1||EN 62841-1:2015||EN 62841-2-2:2015 | |
EU Legislation | 2006/42/EC (MD)||2011/65/EU (RoHS)||2014/53/EU (RED) |
||2015/863/EU (RoHS amendment) | |
ETL control number | 3008099 |
ETL listed | Yes |
ETL text | 6 - 62841-2-2 |
EU SAR value | 0.55 W/kg |
FCC ID | XF6-M7DB7 |
IC ID | 8407A-M7DB7 |
KC certified | No |
UK Regulations | S.I. 2008/1597||S.I. 2012/3032||S.I. 2017/1206 |
UK Standard | EN 300 328 V2.2.2||EN 300 440 V2.1.1||EN 301 489-1 |
V2.1.1||EN 301 489-17 V3.2.4||EN 301 893 V2.1.1||EN | |
50566:2017||EN 55014-1:2017||EN 55014-2:2015||EN | |
61000-6-2:2005||EN 61000-6-3:2007+A1||EN 61000-6 | |
4:2007+A1||EN 62841-1:2015||EN 62841-2-2:2015 | |
WEEE | 5 - Small equipment <50cm |
Torque | |
Torque range max | 9.6 ft-lb |
Torque range min | 2.5 ft-lb |
Torque scatter | ≤ 5 % |
Design & Functions | |
Model type | Quick change |
Output type | Quick change interface |
Quick change interface | IQ-13 |
Shut-off system | Transducer |
Tool family | ICB |
Power | |
Motor power | 500 W |
Motor voltage type | dc |
Motor voltage | 35 V |
Battery information | |
Battery | Li-Io 14/18 V |
Type of battery | 1 Li-ion |
Weight incl. Battery | 3.04 lb |
Noise & vibrations | |
Sound pressure | < 70 dB(A) |
Sound standard | ISO15744 |
Vibration standard | ISO28927-2 |
Vibration value | < 2.5 m/s² |
Speed | |
Speed range max | 897 r/min |
